Built on the renowned Mercedes-Benz Sprinter Chassis and designed for those with a passion for technology and the environment, the E-trek is packed with all the luxury and functionality you could ever imagine in a motorhome. It truly is the perfect eco-conscious travel companion.
Roadtrek’s commitment to the environment, technology and functionality in a motorhome is evident throughout the entire design of the E-trek. It’s more than a vacation getaway, it’s a lifestyle.
Specifications
Specifications| Starting MSRP | $141,518 USD $153,179 CDN |
|---|
| Base Model | Mercedes Sprinter |
|---|
| Seating Capacity | Seats 7 |
|---|
| Sleeping Capacity | Sleeps 2-4 in front single beds & rear twins or king-size bed |
|---|
| Fuel Type | Diesel |
|---|
| Exterior Length | 22’ 9” 6,945 mm |
|---|
| Exterior Width (without mirrors) | 6’ 8” 2,025 mm |
|---|
| Interior Aisle Width | 28" 710 mm |
|---|
| Exterior Height (with roof AC) | 9’ 7” 2,920 mm |
|---|
| Interior Standing Height | 6’ 3” 1,910 mm |
|---|
| Wheelbase | 170" 4,325 mm |
|---|
| Gross Vehicle Weight Rating | 11,030 lbs. 5,003 kg |
|---|
| Occupant & Cargo Carrying Capacity 1 | 2,500 lbs. 1,150 kg |
|---|
| Gross Combined Weight Rating 2 | 15,250 lbs. 6,915 kg |
|---|
| Towing – Tow Weight 3 | 7,000 lbs. 3,200 kg |
|---|
| Towing – Tongue Weight 4 | 750 lbs. 340 kg |
|---|
| Fresh Water Capacity | 33 U.S. gal. 125 L |
|---|
| Black Holding Tank Capacity | 10 U.S. gal 40 L |
|---|
| Gray Holding Tank Capacity | 21 U.S. gal. 80 L |
|---|
| Storage Capacity (with options) | 51 cu. ft. (85 cu. ft.) 1,430 L/51 cu. ft. (2,410 L/85 cu. ft.) |
|---|
| Rear King Bed Size (width x length) | 69” x 78” 1,750 mm x 1,980 mm |
|---|
| Rear Twin Bed Size – Right (width x length) | 25” x 78” 635 mm x 1,980 mm |
|---|
| Rear Twin Bed Size – Left (width x length) | 25” x 78” 635 mm x 1,980 mm |
|---|
| Front Single Bed Size – Right (width x length) - optional feature | 22” x 76” 560 mm x 1,930 mm |
|---|
| Front Single Bed Size – Left (width x length) - optional feature | 22” x 76” 560 mm x 1,930 mm |
|---|
RV Warranty Six year unlimited mileage/km, Peace of Mind motorhome warranty, covering the manufacture of the motorhome, appliances, electronics, plumbing and EcoTrek™ batteries. Original manufactures warranty on all appliances will be applied first. Warranty excludes the complete chassis and AGM batteries which have a normal one year manufacturer’s warranty. | Chassis Warranty Three year/36,000 mile or 60,000 km base limited warranty and Five year/100,000 mile or 160,000 km limited diesel engine components warranty as offered by Mercedes. Refer to chassis manufacturers’ website for details. | - Allowance for weight of occupants, water, propane and cargo. Reduce by weight of optional equipment.
- GCWR includes total weight of vehicle, trailer, equipment, fuel, water, propane, cargo, driver and passengers.
- Maximum towable weight with driver and fuel only. This weight reduced by weight of optional equipment, water, propane, cargo and/or passengers.
- A weight distributing hitch is required for tongue weights over 200 Kg/400 lbs.
|
Coach Features| Air Conditioner | Standard 110 V, 11,000 BTU roof mounted |
|---|
| Armoire | Optional Armoire w/adjustable shelves & drawers (interchangeable w/right 2nd row passenger Capt. Seat) |
|---|
| Awning | Standard 13’ 2” power awning 4,000 mm power awning |
|---|
| Bathroom – Permanently Enclosed | Standard Permanently enclosed with sink & shower |
|---|
| Batteries | Standard Eight 6V, 9,600 W |
|---|
| Detectors | Standard Smoke, propane & CO |
|---|
| DVD Player | Standard DVD Player with 6 Speaker Surround Sound System |
|---|
| EcoTrek 1600 | Optional EcoTrek 1600 Lithium Power Modules ( XL Chassis only) |
|---|
| E-Trek + | Optional EcoTrek 800 + 470 Solar + Voltrek Auto Start + Go Sun Solar Oven |
|---|
| External Power Connection | Standard 110V/30 AMP with detachable power cord |
|---|
| Furnace | Standard Combination furnace/water heater, 16,000BTU |
|---|
| Generator – Under Hood | Standard 24V, 3,500W |
|---|
| GoSun Solar Cooker | Optional GO SUN Solar Oven |
|---|
| Headboard Removable | Optional Removable headboard with shelf for use in XL optioned chassis |
|---|
| Home Theater System | Standard With 5.1 surround sound & dual center speakers with DVD, CD, AM/FM radio, dual use rear speakers |
|---|
| Instant Hot Water | Standard On demand 3.4L/0.9 U.S. gal., 110V |
|---|
| Mattress – Folding (Single, One Mattress) | Optional Single folding for 1st & 2nd row passenger side seats |
|---|
| Mattress – Folding (Two single mattresses) | Optional Single folding for 1st & 2nd row seats |
|---|
| Microwave Oven | Standard 110V convection, 28L/1.0 cu. ft., 1,800W convection/1,000W microwave |
|---|
| Monitor Panel | Standard Water & battery charge levels, battery disconnect surge protection & power monitoring on control panel |
|---|
| Permanent Cabinet | Optional Permanent cabinet with storage for hanging clothing and shelving – replaces driver side 2nd row seat |
|---|
| Portable Solar Cell | Optional Portable Solar Cell 200 Watts |
|---|
| Power Inverter | Standard 24/110 V, 5,000W |
|---|
| Rear power sofa – Forward facing | Standard |
|---|
| “Halo” leather rear power sofa | Standard "Halo" leather rear power sofa |
|---|
| Refrigerator | Standard 12V/110V compressor driven with thermostat, 3.6 cu. ft. |
|---|
| Screen Package | Optional Includes screen for rear cargo door & enhanced magnetic close screen for side door |
|---|
| Sewage Disposal System | Standard 12V macerator sewage pump |
|---|
| Solar Charging System | Standard 240W; daylight with charge controller |
|---|
| Stove – Induction | Standard 110V flush mounted inductive cooktop |
|---|
| Television | Optional 22" flat screen HDTV on rotating bracket |
|---|
| Warp Core Package | Optional Warp Core Pkg: EcoTrek 1600 and 600 Solar: (Must Code ET +) (Available on XL Chassis Only) |
|---|
| Volt Start | Optional Volt Start Autostart Battery Protection Technology |
|---|
| Water Heater | Standard Combination water heater/furnace. 110V, 9L/2.5 U.S. gal. |
|---|
| Water System | Standard On-demand 12V with water pump |
|---|
Chassis Features| 4×4 – Sprinter | Optional Push button on-demand all-wheel drive. Includes manually selectable reduction gear (including both low and high range 4x4) with expanded adaptive electronic aids. |
|---|
| Battery | Standard 760 AMP |
|---|
| Camera – Rearview Backup | Standard |
|---|
| Climate Control | Standard Electronic with glove box cooler |
|---|
| Cooling – Transmission Oil | Standard External |
|---|
| Cruise Control | Standard |
|---|
| Engine | Standard 3.0L CRD V6 turbo diesel BlueTec® |
|---|
| Headlights – Automatic On/Off | Standard |
|---|
| Luxury Chassis OEM Package | Standard Heated driver & passenger seats, Airbags: Driver/Passenger Thorax + Driver/Passenger Window, multi function steering wheel w/trip computer, light & rain sensor, pixel-matrix display, blind spot monitoring, collission prevention assist, lane keeping assist Bi-xenon headlamps & headlamp washing system Becker map pilot nav system, rear view camera, fog lamps, lockable glove compartment |
|---|
| Power | Standard 188HP 140kW/188HP |
|---|
| Radio | Standard Mercedes Becker Map Pilot Navigation System with Bluetooth & on-dash keypad, audio 15 FM/AM, aux-in, USB |
|---|
| Receiver | Standard Class III |
|---|
| Stability Program | Standard Adaptive (accounts for load) |
|---|
| Suspension Package | Standard Stabilizer, rear axle, under frame; stabilizer reinforced at front axle, springs & dampers, front reinforced |
|---|
| Theft Deterrent System | Standard |
|---|
| Tilt Steering | Standard Tilt and telescopic steering wheel |
|---|
| Tire Storage | Standard Vehicle underside between axles |
|---|
| Tires | Standard LT215/85R16E black wall dual rear |
|---|
| Torque | Standard 440 Nm/325 lb.-ft. |
|---|
| Trailer Hitch & Wiring | Standard E40 wire harness & 7 pin connector |
|---|
| Transmission | Standard Automatic 5-speed heavy duty |
|---|
| Wheels – Aluminum | Optional 16” aluminum polished with steel spare |
|---|
| Window Operation – Power | Standard front door power windows |
|---|
| Wiring Harness for Towing | Standard E40 wire harness & 7 pin connector |
|---|
| XL Package | Optional 49 cu.ft of additional storage capacity |
|---|
| CG Paint Package (Charcoal) | Optional Charcoal paint |
|---|
| SE Paint Package (Silver Ice) | Optional Silver Ice paint |
|---|
| CHM Paint Package (Champagne Pearl) | Optional Champagne pearl paint |
|---|
| MB Paint Package (Midnight Black) | Optional Midnight black paint |
|---|
| RR Paint Package (Ruby Red) | Optional Ruby red metallic paint |
|---|
| Custom Paint Color | Optional Custom color paint - customer to provide paint codes |
|---|
| WH Paint Package (Bright White) | Standard |
|---|
Specifications are subject to change without notification.
|
